Products
Power Transformers
a range of high-quality IEC/IEEE/ANSI standard Power Transformers. Our range covers 6 MVA to 200 MVA, 220kV voltage class power and special application transformers.
Designed and manufactured utilizing high-quality materials and production procedures to deliver superior and reliable transformers that exceed the requirements of electrical utility substation applications.
Distribution Transformer- Single Phase
We manufacture a complete range of high-quality IEC Standard 11kV and 33kV voltage class liquid-cooled pole and ground-mounted distribution transformers. Our standard ratings start at 50kVA and go up to 4000kVA, they are designed to comply with the exacting technical demands of Electrical Distribution Network Operators worldwide.
Distribution Transformer- Three Phase
Features:
Ratings: 50kVA to 4000kVA l Primary Voltage: ≤36kV voltage class l Phases: single & three
Class: ONAN/KNAN/ONAF/KNAF l Dielectric: mineral oil or ester fluid l Type: free-breathing or sealed
Pole Mounted:
- Cable Box
– side-mounted – LV - Outdoor Bushing
– top cover – HV / LV – top cover end – HV - Connections
dual primary – two HV bushings connect 2 Փ of 3 Փ system
Ground Mounted:
- Cable Box
side-mounted – HV / LV - Connections
– dual primary – 2 HV bushings connect 2 Փ of a 3 Փ system
Switchgears
A switchgear panel can utilise circuit breakers which automatically protect the system by isolating a circuit when faults or short circuits occur. Detecting and isolating dangerous faults within micro-seconds to minimise and restrict electrical damage to only the area of the fault.
Circuit breakers and fuses are designed to safely interrupt and clear high fault currents, which could attain significantly higher levels than the systems normal operating current.
